PHX.5M.366.XRWT44

Electrical Configuration

Number of contacts Low Voltage

66

Contact Termination Low voltage

Crimp

Insert configuration value

5M.366_44 - 44 (0.7 mm) + 22 (1.3 mm) Low Voltage

Insulator

R: PEEK (mixed multipole)

Rated current

0.7 mm : 3 A, 1.3 mm : 6 A

Test voltage (kV rms) Contact-contact

0.7 mm : 1.65 kV, 1.3 mm : 1.95 kV

Test voltage (kV rms) Contact-shell

0.7 mm : 2.70 kV, 1.3 mm : 1.80 kV

Bucket Dia.

44x0.87 mm, 22x1.6 mm

Contact Dia.

44x0.7 mm, 22x1.3 mm

Wire Size/AWG

26 - 22

Gender

Reverse Gender

Form & Material

Shell style / Model id

PH - Free receptacle with arctic grip and mold stop

Socket / Receptacle

Free

Housing material

Aluminium (nickel plated [SAE AMS QQ N 290], anthracite color) shell and nut, other pieces bronze/brass

Locking system

Ratchet

Keying

X: 5 keys (alpha=100, beta=125, gamma=40, delta=20, plug: female contacts, receptacle: male contacts)

Colour

Grey

Weight

44.26 g

Environment

Technical domain

Motorsport, Security and Defence, Transportation, Aerospace and UAV

Environmental sealing (IP rating)

IP68

Endurance

3000 mating cycles

Temperature range

-20°C / +200°C (max. temperature valid for short periods of use.)

EMI Shielding EIA 364-66A

>= 80 dB (1 GHz), >=70 dB (3 GHz), >= 58 dB (6 GHz), >= 40 dB (10 GHz)

Gunfire vibration

25 Hz - 2000 Hz, 3 axis (Apache helicopter)

Humidity (max)

21 days at 95%

Lighting strike EIA 364-79

10K amps - 6 times

Shock Resistance

300 g [ 3 ms]

Thermal shock

5 cycles: -65°C to +150°C

Vibration-Random

37.8 g rms - 3 axes, 4 hr amb [50 Hz - 2000 Hz]

Vibration-Sine

30 g, 3 axes, 12 hr [10 Hz - 2000 Hz]

Salt Spray Corrosion

max. 48 hr

Cable fixation

Cable termination protection

For overmolding

Fixation type

Mold stop (overmolding)

Jacket cable outside diameter [mm]

14.25 - 28.50 mm
