Receive the same high quality cable assemblies that you've come to expect from LEMO Push-Pull connectors.
Electrical Configuration
- Number of contacts Low Voltage
- 17
- Contact Termination Low voltage
- PCB - Straight
- Insert configuration value
- 0R.317 - 17 low voltage
- Insulator
- L: PEEK (UL 94 / V-0/1.5)
- Rated current
- 2 A
- Contact Dia.
- 0.7
Form & Material
- Shell style / Model id
- EGG - Fixed receptacle, key (G) or key (A)
- Socket / Receptacle
- Fixed Panel Front Mounted
- Housing material
- Crastin® PBT (Polybutylene terephthalate), gray
- Locking system
- Push-pull
- Keying
- 3 keys (alpha=42,gamma=30, plug: male contacts, receptacle: female contacts)
- Weight
- 5.09 g
Environment
- Environmental sealing (IP rating)
- IP50
Technical plans
Dimensions
| A | B | L | M | |
|---|---|---|---|---|
| mm. | 24.5 | 9 | 14 | 12 |
| in. | 0.96 | 0.35 | 0.55 | 0.47 |
CAD
