SNN.M22.GLMG

Electrical Configuration

Number of contacts Low Voltage

22

Contact Termination Low voltage

Crimp

R (max)

8.5 mOhm

Insulator

L: PEEK (UL 94 / V-0/1.5)

Rated current

1.2 A

Test voltage contact-contact

1.9 (kV DC)

Max. Conductor

0.09 mm^2 (AWG 28)

Min. Conductor

0.035 mm^2 (AWG 32)

Air clearance

0.48 mm

Creepage distance

0.48 mm

Bucket Dia.

0.45 mm (0.0177in)

Contact Dia.

0.5 mm (0.0196in)

Wire Size/AWG

32 - 28

Gender

Standard

Form & Material

Shell style / Model id

SNN - Socket, nut fixing, key N, watertight when mated

Socket / Receptacle

Fixed Panel Front Mounted

Housing material

Proprietary sulfone, grey

Locking system

Push-pull

Keying

3 keys (alpha=0, gamma=30, plug: male contacts, receptacle: female contacts)

Colour

Grey

Variant

Grey front nut

Environment

Technical domain

Medical, Test and Measurement, Transportation, Aerospace and UAV

Environmental sealing (IP rating)

IP68

Endurance

>5000 mating cycles

Temperature range

-50°C / +170°C

Steam sterilization

Compiles with ISO 17665:2024 sterilization standard for autoclave, ISO 11135:2014 for EtO, and ISO 11137-1, -2, -3 standards for gamma, e-beam x-ray. For more details on sterilization methods and cycles, please contact us.

Cable fixation

Cable termination protection

Standard back nut (no additional protection)

Jacket cable outside diameter [mm]

1.00 - 12.60 mm
